Engine Power: 72.9 KW (99 hp)
Feeding Capacity: 4.0 kg/s
Cutting Width: 2200 mm
Overall Weight: 3670 kg
Minimum Ground Clearance: 290 mm
Overall Dimensions (L×W×H):
5570×2650×2710 mm (transportation
state); 5730×2540×2940 mm (working
state)
Track Specification: 500×90×59 mm
Track Gauge: 1350 mm
Track Ground Pressure: 20.2 kPa
Fuel Tank Capacity: 140 L
Grain Tank Capacity: 1400 L
Engine Model: V3800-DI-T-ET02
(vertical water-cooled 4-cylinder turbocharged diesel engine)
Transmission Type: Mechanical transmission + hydraulic stepless transmission (HST)
