| Quantity: | |
|---|---|
1. Product Category: Boom Sprayer
2. Machine Structure Type: Self-propelled
3. Operating Pressure (MPa): 0.2–0.5
4. Overall Dimensions (mm): 5950 × 2440 × 3180
5. Boom Length (mm): ≥ 14000
6. Minimum Ground Clearance (mm): ≥ 1030
7. Boom Position: Front-mounted
8. Wheel Track (mm): 1810
9. Boom Lifting Mechanism: Hydraulic
10. Wheelbase (mm): ≤ 2310
11. Engine/Motor Type: Diesel Engine
12. Engine/Motor Structure: Inline 4-cylinder, 4-stroke, Water-cooled
13. Engine/Motor Rated Power / Speed [kW/(r/min)]: 36.8 / 2400
14. Engine/Motor Operating Voltage (V): 24
15. Liquid/Pump Structure: 3-Cylinder Plunger Pump
16. Liquid Pump Rated Pressure (MPa): 3.5
17. Liquid Pump Rated Flow Rate (L/min): 52–112
18. Chemical Tank Capacity (L): ≥ 1000
19. Max. Allowable Pressure in Pressure Hoses (MPa): 8.7 (Pre-distributor) / 2.76 (Post-distributor)
20. Optional Fertilizer Spreader: (Ensures uniform spreading and high efficiency); enables simultaneous fertilizer spreading and chemical application.
